Technical features of supercharger bracket

Technical characteristics:

1. A turbocharger bracket, characterized in that it comprises a base and a bracket body arranged on the base, the bracket body is provided with a turbocharger oil inlet channel and a turbocharger oil return channel, and the base is provided with a return The oil cavity and the oil return port of the bracket are connected with the oil return passage of the supercharger and the oil return port of the bracket. 2. The supercharger bracket according to claim 1, wherein the base is provided with a temperature sensor interface communicating with the oil return cavity, and an oil return baffle is provided in the oil return cavity, so The oil return baffle is located between the temperature sensor interface and the oil return port of the bracket, and the oil return baffle and the temperature sensor interface are respectively located on both sides of the outlet of the turbocharger oil return passage. The supercharger bracket according to claim 2, wherein the height of the oil return baffle is greater than the radial dimension of the temperature sensor interface. 4. The supercharger bracket according to claim 2, wherein the base is provided with a cleaning port communicating with the oil return cavity, and the cleaning port and the oil return port of the bracket are respectively located in the On opposite sides of the oil return cavity, the temperature sensor interface is located between the cleaning port and the oil return passage of the turbocharger. The supercharger bracket according to claim 2, wherein the oil return baffle is provided with an oil return hole. The supercharger bracket according to claim 1, wherein the bracket body is provided with a pressure sensor interface, and the pressure sensor interface is in communication with the supercharger oil inlet channel. 7. The supercharger bracket according to claim 6, wherein the supercharger oil inlet passage includes a bracket oil inlet provided on a side of the bracket body, and a first An oil passage, and a supercharger oil inlet provided on the top of the bracket body, the first oil passage communicates the bracket oil inlet and the supercharger oil inlet, and the pressure sensor interface is connected to the The first oil passage is connected. 8. The turbocharger bracket according to claim 6, wherein the turbocharger oil return passage comprises a turbocharger oil return port arranged on the top of the bracket body, and a turbocharger oil return port arranged in the bracket body. The second oil passage communicates with the oil return port of the supercharger and the oil return cavity. The supercharger bracket according to claim 1, wherein the bracket body is provided with a supercharger connection structure for connecting with a supercharger. 10. The supercharger bracket according to claim 1, wherein the base is provided with an engine connection structure for connecting with an engine.
