Technical features of hot melt machine that is convenient for manual operation

Technical characteristics:

1. A hot melt machine that is convenient for manual operation, comprising: a support frame, a receiving mechanism, a driving mechanism, and a hot melt module; the hot melt module, the receiving mechanism, and the driving mechanism are all set in the place The supporting frame; the supporting frame includes a supporting bottom frame, a bearing plate, a top plate and four supporting columns; the bearing plate is arranged between the supporting bottom frame and the top plate, and the supporting bottom frame passes through the four The supporting column is connected to the receiving plate and the top plate; the top plate is provided with four limit sliding columns on the side facing the receiving plate; the receiving mechanism includes a connecting bottom plate, a receiving platform and a fixing component; the receiving platform It is connected to the receiving plate through the connecting bottom plate; the receiving platform is provided with a receiving groove, and the receiving groove is used to receive processed plastic parts; the fixing component is arranged in the receiving groove; the fixing component includes A compression spring and a fixed plate, the fixed plate is elastically connected to the inner side wall of the receiving groove through the compression spring; the driving mechanism includes an electric assembly, a manual assembly, a worm gear module, and a drive screw; the electric assembly includes The drive motor, the first drive gear, the transmission chain, and the second drive gear; the drive motor is connected to the support base frame, the drive motor is drive connected to the first drive gear, the first drive gear and the The second driving gears are all adapted to the transmission chain, the first driving gear is drivingly connected to the second driving gear through the transmission chain; the second driving gear is connected to the worm gear module through the worm gear module. The driving screw is drivingly connected, and one end of the driving screw away from the worm gear module is rotatably connected with the top plate; the manual assembly includes a rotating rod, a rotating seat, and a rotating handle; the rotating seat and the connecting bottom plate Connected, the rotating rod passes through the rotating seat and is rotatably connected with the rotating seat, one end of the rotating rod is connected with the second drive gear, and the other end of the rotating rod is connected with the rotating handle; The connecting plate of the hot melt module is provided with threaded holes and four sliding holes. The threaded holes are matched with the driving screw rod, and the driving screw rod is inserted into the threaded hole and connected with the hot melt. The connecting plate of the module is drivingly connected; the sliding holes are adapted to the limit sliding posts, and each limit sliding post is inserted in one of the sliding holes and slides with the connecting plate of the hot melt module connect. 2. The heat-melting machine that is convenient for manual operation according to claim 1, wherein the fixing assembly includes a plurality of the compression springs, and the fixing plate is connected to the inner side wall of the receiving groove through each of the compression springs. Flexible connection. 3. The hot melt machine convenient for manual operation according to claim 2, wherein each of the compression springs is uniformly arranged on the fixing plate. The hot melt machine convenient for manual operation according to claim 1, wherein a cushion pad is provided on the side of the fixing plate facing away from the compression spring. 5. The hot melt machine convenient for manual operation according to claim 4, wherein the cushion pad is a soft plastic pad. The hot melt machine that is convenient for manual operation according to claim 4, wherein the cushioning pad is a soft rubber pad. The hot melt machine that is convenient for manual operation according to claim 4, wherein the cushion pad is a soft silicone pad. 8. The hot melt machine that is convenient for manual operation according to claim 4, wherein the cushion pad is provided with anti-skid patterns. 9. The hot melt machine that is convenient for manual operation according to claim 1, wherein the turning handle is a steering wheel handle. 10. The hot melt machine that is convenient for manual operation according to claim 1, wherein the rotating seat is provided with

A rolling bearing, the rolling bearing is adapted to the rotating rod, and the rotating rod is inserted in the rolling bearing to rotate relative to the rotating seat.
