Technical characteristics of anti-stranding device for water intake pump ship

An anti-stranding device for a water intake pump ship, which is characterized by comprising a depth sounder and a telescopic device. The depth sounder and the telescopic device are respectively installed on the shore side and the water side of the hull, and the telescopic device adopts an integrated type The electro-hydraulic support arm is composed of a cylinder, a telescopic rod, a driving element, and an oil pipe. The telescopic rod is arranged inside the cylinder and is movably connected with it. The bottom of the telescopic rod is provided with a support plate, and the side end of the cylinder is provided with The drive element is connected to both ends of the cylinder through two oil pipes. 2. The anti-grounding device for a water intake pump ship according to claim 1, wherein the support plate is installed transversely at the bottom of the telescopic pole. 3. The anti-grounding device for a water intake pump ship according to claim 2, wherein the support plate is an arc-shaped plate and is fixedly arranged at the bottom of the telescopic rod. The anti-stranding device of the water intake pump ship according to claim 2, wherein the supporting plate is two pieces, which are respectively hingedly arranged on both sides of the telescopic rod, and a limit block is arranged at the hinged joint. The anti-grounding device for a water intake pump ship according to claim 3 or 4, wherein a drill bit or an anchor is installed at the bottom of the telescopic rod.
