Refrigeration equipment manufacturing method and technical realization elements

Technical realization elements:

3. This utility model aims to solve at least one of the technical problems existing in the prior art.

4. For this reason, one aspect of the present utility model proposes a refrigeration equipment.

5. In view of this, according to one aspect of the present utility model, the present utility model proposes a refrigeration equipment, including: a main body, the main body includes an opening; the lighting device is arranged in the main body, the lighting device can be directed to the inside of the main body through the opening Irradiate.

6. The refrigeration equipment proposed by this utility model includes a main body and a lighting device. The lighting device is arranged on the main body. The main body is provided with an opening. The personnel can put materials into the main body through the opening or take out materials from the main body. The lighting device can pass through The opening illuminates the inside of the main body, so that even in a dark environment, personnel can clearly see the materials contained in the main body, which improves the scope of application of the refrigeration equipment and makes the refrigeration equipment no longer limited to ambient light.

7. In addition, the refrigeration equipment in the above technical solution provided by the present utility model may also have the following additional technical features:

8. In the above technical solution, further, the lighting device includes: a base provided on the main body; and a light emitting element provided on the base, located on the side of the base facing the opening.

9. In this technical solution, the lighting device includes a base and a light-emitting device, the base is arranged on the main body, the light-emitting element is arranged on the base, and is arranged on the side of the base facing the opening, and the base can be enlarged The distance between the light-emitting element and the opening further increases the illumination range of the light-emitting element, which can illuminate the inside of the main body more comprehensively, and avoid the light scattering of the light-emitting element, that is, irradiate the area behind the refrigeration equipment.

10. In any of the above technical solutions, further, the base is recessed toward the side of the opening.

11. In this technical solution, the side of the base facing the opening is recessed, so that the light-emitting element can be protected in the recess.

12. In any of the above technical solutions, further, the side of the base facing the opening is a curved surface, which is curved in a direction from close to the main body to away from the main body.

13. In this technical solution, the side of the base facing the opening is a curved surface, and the curved surface can gather and emit light, thereby increasing the brightness.

14. In any of the above technical solutions, further, the side of the back of the base leaving the opening is curved, and the side of the back of the base leaving the opening has the same bending direction as the side of the base facing the opening.

15. In this technical solution, the side of the base away from the opening and the side of the base facing the opening have the same bending direction, thereby making the overall structure of the lighting device symmetrical, avoiding "top-heavy" and other problems, and the curved surface has good roundness. Avoid harm to users and improve the safety of refrigeration equipment.

16. In any one of the above technical solutions, further comprising: an imaging element, which is provided in the lighting device, and the imaging element can photograph the inside of the main body through the opening.

17. In this technical solution, the refrigeration equipment also includes a camera element, which can shoot the inside of the main body through the opening, so that the quantity and type of materials contained in the main body can be known, and it can also be known that the main body What kind of material is taken out of the inside, and the specific quantity taken out, which facilitates the intelligent control of the refrigeration equipment.

18. In any of the above technical solutions, further, the lighting device further includes: a human body sensing element, which is provided on the base, is electrically connected to the light-emitting element, and is located on the side of the base facing the opening.

19. In this technical solution, the lighting device also includes a human body sensing element, which is arranged on the base and is electrically connected to the light-emitting element, so that the light-emitting element can be turned on when a person approaches the refrigeration equipment, and after the person is away from the refrigeration equipment, Turn off the light-emitting element, thereby ensuring lighting while saving electrical energy.

20. In any of the above technical solutions, further, the base is located on the side wall of the main body, and the light-emitting element is elongated and arranged along the side wall of the base; or the base is located on the side wall of the main body, and the light-emitting element The number is multiple, and multiple light-emitting elements are distributed along the side wall provided on the base.

21. In this technical solution, since the main body has a certain length, the use of long light-emitting elements arranged along the side walls of the base can increase the amount of light-emitting elements that can illuminate the inside of the main body as much as possible. Scope, thereby reducing the dead angle inside the main body.

22. Similarly, the use of multiple light-emitting elements arranged along the side walls of the base can increase the range of the light-emitting elements that can illuminate the inside of the main body as much as possible, thereby reducing the dead angle inside the main body.

23. In any of the above technical solutions, further, it further includes: a door movably arranged on the main body for opening and closing the opening.

24. In this technical solution, the refrigeration equipment also includes a door, which can be movably arranged on the main body to open and close the opening. The door can be used to reduce the heat exchange between the inside of the main body and the outside, thereby improving cooling The insulation performance of the equipment.

25. In any of the above technical solutions, further, the door body is a light-transmitting part.

26. In this technical solution, the door body is a light-transmitting part, and the lighting device can illuminate the inside of the main body through the door body, thereby facilitating the user to observe the materials inside the main body without opening the door body, thereby lowering the door The number of openings of the body improves the heat preservation performance of the refrigeration equipment.

27. In any of the above technical solutions, further, the door body can slide relative to the main body.

28. In this technical solution, the sliding door body can keep moving inside the opening to avoid affecting the lighting device when the door body is opened or closed.

29. In any of the above technical solutions, further, the opening is located at the top of the main body.

30. In this technical solution, the opening is provided on the top of the main body, and due to the influence of gravity, more materials can be placed inside the main body, and it is also convenient for the user to observe the inside of the main body.

31. In any of the above technical solutions, further, the lighting device is located at the edge of the opening.

32. In this technical solution, the lighting device is arranged on the edge of the opening, which facilitates the placement of materials inside the main body and also facilitates the removal of materials from the inside of the main body.

33. In any of the above technical solutions, further, the lighting device is inclined toward the opening.

34. In this technical solution, the illuminating device is arranged obliquely, which can reduce the footprint of the refrigeration equipment, and can make the light emitting element closer to the opening, thereby increasing the illumination range of the light emitting element to the inside of the main body.

35. The additional aspects and advantages of the present utility model will become obvious in the following description, or be understood through the practice of the present utility model.
