Panel light and panel light group manufacturing method

10. By adopting the above technical solutions, the influence of the sensor on the light output of the light-emitting surface can be reduced; at the same time, the sensor can share the packaging material at the corner of the panel light, so there is no need to add additional packaging materials to the sensor. Individually protected, thus saving the packaging material of the panel light.

11. In some embodiments, the panel light includes a housing and a diffuser plate, one side of the housing has an opening, an edge of the opening is provided with a limiting flange, and the diffuser plate is embedded in the diffuser plate. The opening is pressed against the limiting flange, the outer surface of the diffusion plate is the light emitting surface, and the sensor is embedded on the diffusion plate.

12. By adopting the above technical solution, the height of the sensor protruding from the outer surface of the diffuser plate can be reduced, and the shielding of the light from the diffuser plate by the sensor to the surroundings can be reduced.

13. In some embodiments, a limit plate is fixedly connected to the sensor, and a mounting hole is provided on the diffuser plate.

The sensor is inserted through the installation through hole, the limiting plate is in contact with the outer surface of the diffuser plate, and a part of the limiting plate is sandwiched between the limiting flange and the outer surface of the diffuser plate. between the diffuser plates.

14. By adopting the above technical solution, not only the installation stability of the sensor can be increased, but also the limit flange and the limit plate can jointly support the diffuser plate, thereby reducing the diffusion plate under its own gravity and other forces. Bending deformation.
