Manufacturing method of novel jacket transportation fixing device

Technical summary

The utility model discloses a new type of jacket transportation fixing device, which includes a fixing seat, a fixing plate, a support arm, a pressing plate, a fixing bolt and a sliding block. The bolt makes the support arm push the pressure plate, the sliding block advances along the guide groove, and presses the pressure plate to the pipe. The operation is simple and convenient. Under the premise of ensuring the stability of the pipe transportation process, the installation and disassembly speed of the pipe is increased; when the pulley is fixed, Only need to adjust the screw rod, the screw rod pushes the extrusion block forward. During the advancement of the extrusion block, the compact lifts the extrusion block and presses the extrusion block against the pulley, so that the pulley is fixed and the operation is simple and convenient. And will not cause damage to the pulley. Will not cause damage to the pulley. Will not cause damage to the pulley.
