Manufacturing method of grinding device for bearing processing

Technical characteristics:

1. A grinding device for bearing processing, comprising a mounting plate (1), characterized in that: the front of the mounting plate (1) is provided with a mounting hole (2), and the inner wall of the mounting hole (2) is movably connected with Install the bolt (3), the top of the mounting plate (1) is fixedly connected with a motor (4), the output shaft of the motor (4) is fixedly connected with a rotating shaft (5) through a coupling, the rotating shaft (5) A column block (6) is fixedly connected to the outer wall of the column block (6), a first anti-skid pad (7) is fixedly connected to the front surface of the column block (6), and the outer wall of the column block (6) is provided with an external thread (8), the The outer wall of the column block (6) is movably connected with a sleeve column (9), the inner wall of the sleeve column (9) is provided with an internal thread (10), and the front surface of the internal thread (10) is fixedly connected with a second anti-skid pad ( 11) The front of the sleeve column (9) is provided with a through hole (13), the outer wall of the sleeve column (9) is movably connected with a bearing body (14), and the top of the mounting plate (1) is fixedly connected There is a stabilizing plate (15); the front of the stabilizing plate (15) is fixedly connected with a stabilizing bearing (16), the top of the stabilizing plate (15) is fixedly connected with a polishing mechanism (17), the polishing mechanism (17) It includes a movable seat (1701), the front of the movable seat (1701) is movably connected with a support rod (1702), the front of the support rod (1702) is fixedly connected with a movable shaft (1703), the movable shaft (1703) A grinding seat (1704) is fixedly connected to one end of the grinding seat (1704), and a grinding layer (1705) is fixedly connected to the bottom of the grinding seat (1704). 2. A grinding device for bearing processing according to claim 1, characterized in that: the shape and size of the mounting hole (2) and the shape and size of the mounting bolt (3) are matched with each other, and the mounting bolt (3) The mounting hole (2) penetrates the top of the mounting plate (1) and extends to the bottom of the mounting plate (1). 3. A grinding device for bearing processing according to claim 1, characterized in that: the shape and size of the column block (6), the shape and size of the sleeve column (9) and the shape and size of the stable bearing (16) are all Are matched with each other, and the column block (6) is movably connected to the stable bearing (16) through the first anti-skid pad (7) and the second anti-skid pad (11) through the external thread (8), and the first anti-skid pad (7) and The second anti-skid pad (11) is a rubber anti-skid pad. The grinding device for bearing processing according to claim 1, wherein the outer wall of the internal thread (10) is fixedly connected with an anti-skid layer (12), and the anti-skid layer (12) is a rubber anti-skid layer. 5. A grinding device for bearing processing according to claim 1, characterized in that: the shape and size of the through hole (13) and the shape and size of the rotating shaft (5) are matched with each other, and the rotating shaft (5) passes The penetration hole (13) penetrates one end of the sleeve column (9) and extends to the other end of the sleeve column (9). 6. A grinding device for bearing processing according to claim 1, characterized in that: the shape and size of the stable bearing (16) and the shape and size of the rotating shaft (5) are matched with each other, and the stable plate (15) passes The stable bearing (16) is movably connected with the rotating shaft (5). The grinding device for bearing processing according to claim 1, characterized in that: the shape and size of the movable seat (1701) and the shape and size of the support rod (1702) are matched with each other, and the movable seat (1701) The movable shaft (1703) is movably connected with the support rod (1702).
