Manufacturing method of easy-to-use sliding hammer

1. The utility model relates to the technical field of material equipment on an anchor chain production line, specifically a sliding hammer that is easy to use.

Background technique:

2. Before the automatic feeder is used, the material frame is an integrated design and cannot be disassembled. The operator needs to place all the bars evenly on the equipment. The labor intensity is very heavy, and the daily work intensity needs to be carried about 2

3 tons of bar material, the automatic feeding problem was solved after the automatic feeding machine was put in, but the design of the material frame remained unchanged. Based on the above problems, the original design of the material frame needs to be changed to make it a detachable material frame , Use the crane to directly place the entire material frame on the automatic feeding equipment, and then pull out the plug. Therefore, a tool that can be easily drawn, namely the "sliding hammer", is needed. Now we need a convenient sliding hammer , But the existing easy-to-use sliding hammers have many problems or defects:

3.1. The existing sliding hammers have low safety performance during use. The sliding hammers will slide on the sliding rods, which may cause accidental injury to the staff, and even accidentally take out the latches on the material trucks during transportation and cause the materials to scatter. A situation that causes interference to the working environment occurs in one place;

4.2. In addition, the existing sliding hammer is not tightly connected with the bolt on the material carrier, and it is easy to cause the hook to separate from the bolt when the angle changes, and the staff needs to hang it again, which reduces the work efficiency.
