Manufacturing method of assembly jig for computer radiator production

1. This utility model relates to the field of assembly fixtures, and more specifically, to an assembly fixture for the production of computer radiators.

Background technique:

2. A large number of integrated circuits are used in computer components. As we all know, high temperature is the enemy of integrated circuits. High temperature will not only cause unstable operation of the system, shorten the service life, and may even burn out some parts. The heat that causes high temperatures does not come from outside the computer, but inside the computer, or inside the integrated circuit. The function of the radiator is to absorb the heat, and then dissipate it to the inside or outside of the case to ensure that the temperature of the computer components is normal.

3. Computer radiators generally need to be assembled together after the production is completed. When assembling computer radiators, it is generally necessary to use an assembly fixture to fix the bracket, and then install other fan lights into the bracket, but the existing assembly fixture is fixed It is inconvenient to rotate behind the bracket. For this reason, we have proposed an assembly jig for the production of computer radiators.
