Elements of technical realization of storage racks for spline broaches

Technical implementation elements:

3. In view of the deficiencies of the prior art, the present invention provides a storage rack for spline broaches, which solves the problems raised in the above background technologies.

4. In order to achieve the above purpose, the present invention is realized through the following technical solutions: a storage rack for spline broaches, comprising a support table, the upper surface of the support table is fixedly connected with a first connecting plate, and the first A receiving component is fixedly installed on the side of the connecting plate, and a connectable component is arranged on the top of the first connecting plate;

5. The storage assembly includes several groups of storage bins arranged on the side of the first connecting plate, the top of the several groups of the storage bins is provided with a cover plate, the interior of the storage bin is provided with a buffer pad, and the surface of the buffer pad is opened. There are several groups of broach limit grooves, and the top edges of the several groups of said broach limit grooves are provided with side grooves;

6. The connectable assembly includes a second connecting plate connected to the top of the first connecting plate, a card plate is provided at the lower end of the second connecting plate, and a card is provided on the top of the first connecting plate and the second connecting plate. Several groups of first bolts are threadedly connected to the bottom of the clamping plate, and first bolt grooves are provided at the upper ends of the first connecting plate and the second connecting plate corresponding to the clamping grooves.

7. As a further technical solution of the present invention, two sets of handles are fixedly connected to the upper surface of the buffer pad, a door suction head is fixedly connected to the side of the first connecting plate and located on the back of the cover plate, and the storage compartment is Several groups of connection blocks are fixedly connected to the side of the .

8. As a further technical solution of the present invention, each group of the storage bins is adapted to the size of each group of the buffer pads, and the size of each group of the broach limit grooves is the same.

9. As a further technical solution of the present invention, the door suction head and the door suction hole opened on the back of the cover plate are magnetically connected.

10. As a further technical solution of the present invention, several groups of connecting block grooves are opened on both sides of the bottom of the first connecting plate and the second connecting plate and at the corresponding connecting blocks, and the first connecting plate and the second connecting plate are connected. Both ends of the plate are provided with several groups of second bolt grooves, and the interiors of the several groups of the second bolt grooves are threadedly connected with second bolts.

11. As a further technical solution of the present invention, the size of the card plate and the card slot are adapted, and the second connecting plate and the first connecting plate are connected by the card plate and the card groove and the first bolt and the first bolt. Slots are connected.

12. As a further technical solution of the present invention, a through hole is opened on the side of the connecting block corresponding to the second bolt groove, and the receiving bin, the first connecting plate and the second connecting plate are all connected through the connecting block and the connecting block recess. The groove is connected with the second bolt.

13. Beneficial effects

14. The utility model provides a storage and placement rack for a spline broach. Compared with the prior art, it has the following beneficial effects:

15.1. A storage rack for spline broach, through the function of the broach limit slot, the spline broach can be limited and fixed, and the coordination of the buffer pad can prevent the spline broach from being damaged, and it is easy to handle By using the magnetic connection between the door suction slot opened on the cover plate and the door suction head, the cover plate can be stabilized and the internal operation of the storage bin can be facilitated.

16.2. A storage rack for spline broaches, through the card slot opened on the top of the first connecting plate and the card plate designed below the second connecting plate, it is convenient to realize the connection between the first connecting plate and the second connecting plate, and The design of the second connecting plate can continue to realize the connection between the two second connecting plates, thereby increasing the number of storage components, facilitating the storage of more spline broaches, and improving the storage efficiency.
