Elements of technical realization of pressure end cleaning device for wood board pressing in building construction

Technical implementation elements:

4. The purpose of this utility model is to provide a pressure end cleaning device for building and construction, which is pressed together by wooden boards, so as to solve the problem that the cleaning device can only clean the local area of the pressure end in the above-mentioned background technology, and the position and angle of the cleaning brush plate cannot be adjusted. Clean the entire pressure end of the problem.

5. In order to achieve the above purpose, the present utility model provides the following technical solutions: a pressure end cleaning device for building and construction by pressing wooden boards includes: a fixed bottom plate, a buckle is provided on the fixed bottom plate, and a central position on the upper surface of the fixed bottom plate is provided with There are two slide rails at the bottom end of the fixed base plate, a rotating plate, a motor is arranged on the upper surface of the rotating plate, two fixed frames distributed in parallel are arranged on the rotating plate, and a rotating shaft is arranged in the center of the rotating plate. The shaft passes through the two fixing frames, a rotating brush wheel is sleeved on the outer side of the rotating shaft, and a driven runner is arranged on the rotating shaft.

6. Preferably, the fixed bottom plate has a square plate-like structure, a clamping slot is provided at the center of the upper surface of the fixed bottom plate, and the fixed bottom plate is sleeved on two parallel distributed slide rails.
