Elements of Technical Realization of Integrated Side Roofs for Rail Transit Vehicles

Technical implementation elements:

4. (1) Technical problems to be solved

5. The problem to be solved by the present invention is to provide an integrated side roof for rail transit vehicles to overcome the defects of the prior art that the installation process of the vehicle side roof is complicated, time-consuming and labor-intensive.

6. (2) Technical solutions

7. In order to solve the technical problem, the present utility model provides an integrated side roof for rail transit vehicles, which includes a side roof assembly, the side roof assembly is installed at the vehicle door body, and the side roof assembly includes a side roof main body and a side roof assembly. A side top external screen, the side top external screen is attached to the bottom surface of the side top main body, a display screen is installed on the side top main body, and a mounting groove is arranged on the side top external screen, and the display screen passes through the side top external screen. Through the side top body and placed in the installation slot, the surface of the display screen is kept horizontal with the bottom surface of the side top outer screen, the side top body is hinged with a connecting plate, and the connecting plate is fixed on the On the outer vehicle body, a plurality of lock catches are also rotatably installed on the side roof main body, the lock buckles cooperate with the outer vehicle body to lock the side roof main body, and a plurality of warnings are also installed on the side roof main body The warning light passes through the side roof main body and protrudes from the surface of the side roof outer screen, the warning light is located under the display screen, and the side roof components are integrated during assembly, and there is no need to separate each The parts are separately mounted on the vehicle body, and the surface between the display screen and the side roof outer screen is flat and seamless.
