Elements of Technical Realization of Fixtures for Plastic Pipe Fittings in Production

3. In view of this, the present invention provides a plastic pipe product fixture for production, which can not only be positioned and fixed automatically, but also can be automatically discharged after processing.

4. In order to solve the above-mentioned technical problems, the present utility model provides a plastic pipe fitting product fixture for production, which includes a v-shaped block, and a rotary clamping cylinder for fixing the pipe fittings is fixedly installed on both sides of the v-shaped block. Both ends of the block are provided with positioning devices for positioning the pipe fittings, the bottom of the v-shaped block is respectively fixed with a long stroke cylinder and a short stroke cylinder for discharging the pipe fittings, and the bottom of the v-shaped block is provided with a long stroke cylinder and a short stroke cylinder. Through hole for short stroke cylinder fit.

5. Further, the positioning device includes a connecting block fixedly installed at one end of the v-shaped block, a positioning rod is rotatably connected to the connecting block, a connecting rod is rotatably connected to the bottom of the positioning rod, and the other end of the connecting rod is connected with the connecting rod. The moving shaft of the positioning cylinder is rotatably connected, and the positioning cylinder is fixedly installed at the bottom of the v-shaped block.

6. Further, support blocks with arc surfaces are fixedly connected to the moving shafts of the long-stroke cylinder and the short-stroke cylinder.

7. Further, a rubber block is fixedly connected under the pressing block of the rotary clamping cylinder.

8. Further, there are 4 rotating clamping cylinders in total.

9. the beneficial effects of the above-mentioned technical scheme of the present utility model are as follows:

10.1. By setting the positioning device, after manually placing the pipe fittings, the positioning is automatically completed, which ensures the processing accuracy and product quality;

11.2. By setting a long-stroke cylinder and a short-stroke cylinder, after the shaft pipe fittings are held up, the lifting strokes of the long-stroke cylinder and the short-stroke cylinder are different, so that the pipe fittings are inclined and then fall down and discharged by gravity, which improves the processing efficiency.
