Double Disk Grinding

Double Disk Grinding

For small diameter metal parts, our efficient double-disc grinding service is unparalleled in producing high-volume parts with micron tolerances. Our vertical double disc grinder not only has extraordinary dimensional tolerances, but also produces surface finishes, end features, parallelism and flatness designed to meet various manufacturing needs.

High-volume flexibility and precision

Our full-service capabilities include two vertical double-disc grinders with huge throughput, allowing us to handle the largest orders and tight production schedules, while grinding parts to close tolerances. Solid parts and pipes, including thin-walled pipes, can be processed without a heat-affected zone, and the surface finish is significantly improved.

Our double-disc grinding process grinds both sides of the workpiece at the same time, and the same amount of material can be removed from both sides in one operation. This not only ensures better control of dimensional tolerances, flatness and parallelism, but also reduces internal stress and improves part stability during secondary processing.

Our double-disc grinding is suitable for almost any metal and can meet a wide range of manufacturing requirements and demanding specifications-providing cost-effective thickness dimensions for a large number of small parts (such as fine blanking, die-casting and sintered metal parts). This capability allows us to produce small metal parts for customers with a variety of applications, including bearing races, cam lobes, blade rotors, washers, impellers, washers, nuts and donuts, driven sprockets, gears, VTC main body, flange bearing, sealing ring, cam ring, VTC sprocket, pinion gear and fuel injector parts.

Our professional double disc grinding process

Our equipment is specially designed for grinding small diameter parts, which can accurately control the length and verticality. Our grinders have multi-axis control and can be specifically configured for your application to provide the right shape and finish with the best degree of automation. Our vertical double-disc grinder also provides high rigidity and excellent durability, making it stable and reliable in high-precision and heavy-duty grinding. In the through-feed mode, the components are continuously fed through the machine to achieve throughput that far exceeds any manual or even pick-and-place loading method.

Our in-house grinding wheel inventory supports custom engineering to provide superior performance even for the most challenging applications. Our double-disc grinding wheels have an excellent service life, which optimizes the grinding time period and provides consistency throughout the operation of the part. Our grinding process also achieves the best parallelism and consistent flatness for materials that need to be stacked or spotted during processing operations.

Our equipment, control interface and well-trained staff work together to ensure that your project is completed quickly and efficiently. Online inspection can be deployed to automatically adjust the size to improve accuracy and repeatability. Features such as simple setup and control, measurement integration, adjustable spindle stiffness, automatic height adjustment, and wheel dressing assisted customization, while speeding up operations and helping to ensure precise and consistent results.

Please contact us if you need: zhang@pride-cnc.com
