A Technical Realization Element for Furniture Design

Technical implementation elements:

5. In order to overcome the disadvantage that the position of the punching machine of the existing device is relatively fixed, the technical problem of the present invention is to provide a punching table for furniture design which can easily adjust the position of the punching machine.

6. Technical solution: a punching table for furniture design, including a punching table, a sliding rail frame, a sliding connecting frame, a first sliding rod, a punching machine, a first spring, an adjustment mechanism and a clamping mechanism, The right part of the hole platform is slidably connected with a sliding guide frame, the sliding guide frame is slidably connected with a sliding connection frame, a first spring is connected between the sliding connection frame and the sliding guide frame, and the front and rear sides of the sliding connection frame are slidably connected with The first sliding rod, a punching machine is connected between the sides of the first sliding rods that are close to each other, the punching table is provided with an adjustment mechanism for adjusting the punching machine, and the punching table is provided with a clamping device for clamping the plate mechanism.

7. In addition, it is particularly preferred that the adjusting mechanism includes an adjusting frame, a second sliding rod, an adjusting rod and a slider, the left side of the sliding connection frame is connected with an adjusting frame, and the four corners of the top of the punching table are connected with a second sliding block. The rod and the second sliding rod are all slidably connected with the adjustment frame, an adjustment rod is slidably connected in the adjustment frame, a slider is slidably connected on the adjustment rod, and the bottom of the slider is connected with the punching machine.

8. In addition, it is particularly preferred that there are four second sliding rods in total to enhance sliding stability.

9. In addition, it is particularly preferred that the clamping mechanism includes a splint, a sliding plate and a second spring, the front and rear parts of the punching table are slidably connected with a sliding plate, the top of the sliding plate is connected with a splint, and the sliding plate is connected with the punching plate. A second spring is connected between the platforms.
